CPU Siemens - CPU 6ES7414-2XL07-0AB0 - SIMATIC S7-400 - CPU 414-2
Mã sản phẩm: CPU 6ES7414-2XL07-0AB0
Mô tả: SIMATIC S7-400, CPU 414-2 Central processing unit with: Work memory 2 MB, (1 MB code, 1 MB data), 1st interface MPI/DP 12 Mbit/s, 2nd interface PROFIBUS DP
Hãng sản xuất: Siemens - Germany
Liên hệ: Mr. Lên: 0906 7654 89
Email: Sales@tctech.com.vn
Công ty TC-Tech chuyên cung cấp các sản phẩm và giải pháp sử dụng công nghệ của Siemens, thiết bị điện điều khiển công nghiệp, thiết bị tự động hóa đo lường, thiết bị khởi động, đóng cắt, động cơ…
- PLC Simatic S7-200, S7-1200, S7-300,S7-400, S7-1500..
- Logo – bộ điều khiển logic
- Màn hình cảm ứng công nghiệp HMI Touch Panel,
- Biến tần- Inverter,
- Contactor, Relay,
- Soft-starter( Khởi động mền)
- Simocod Sinamic,
- Encoder.
Các dòng sản phẩm khác:
| 6ES7412-2EK07-0AB0 – PLC SIEMENS S7-400 CPU 412-2PN |
| 6ES7422-1FH00-0AA0 – Module PLC S7-400 SM 422 16DO |
| 6ES7416-5HS06-0AB0 – PLC SIEMENS S7-400 CPU 416-5H |
| 6ES7431-7QH00-0AB0 – Module PLC S7-400 SM431 16AI |
| 6ES7407-0KR02-0AA0 – Bộ Nguồn PLC Siemen S7 – 400 PS 407: 10 A |
| Order code | Description |
| 6ES7511-1AK02-0AB0 | SIMATIC S7-1500, CPU 1511-1 PN, Central processing unit with working memory 150 KB for program and 1 MB for data, 1. interface: PROFINET IRT with 2 port switch, 60 NS bit-performance, SIMATIC memory card necessary |
| 6ES7513-1AL02-0AB0 | SIMATIC S7-1500, CPU 1513-1 PN, central processing unit with working memory 300 KB for program and 1.5 MB for data, 1. interface: PROFINET IRT with 2 port switch, 40 NS bit-performance, SIMATIC memory card necessary |
| 6ES7515-2AM01-0AB0 | SIMATIC S7-1500, CPU 1515-2 PN, Central processing unit with work memory 500 KB for Program and 3 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface: PROFINET RT, 30 ns bit performance, SIMATIC Memory Card required |
| 6ES7516-3AN01-0AB0 | SIMATIC S7-1500, CPU 1516-3 PN/DP, Central processing unit with Work memory 1 MB for program and 5 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface: PROFINET RT, 3rd interface: PROFIBUS, 10 ns bit performance, SIMATIC Memory Card required |
| 6ES7517-3AP00-0AB0 | SIMATIC S7-1500, CPU 1517-3 PN/DP, Central processing unit with work memory 2 MB for Program and 8 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface: PROFINET RT, 3rd interface: PROFIBUS, 2 ns bit performance, SIMATIC Memory Card required |
| 6ES7518-4AP00-0AB0 | SIMATIC S7-1500, CPU 1518-4 PN/DP, Central processing unit with work memory 4 MB for program and 20 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface: PROFINET RT, 3rd interface: Ethernet, 4th interface: PROFIBUS, 1 ns bit-performance, SIMATIC Memory Card required |
| 6ES7518-4AX00-1AC0 | SIMATIC S7-1500, CPU 1518-4 PN/DP MFP, inclusive C/C++ Runtime and OPC UA Runtime license working memory 4 MB for program and 20 MB for data, 1. interface: PROFINET IRT with 2 port switch, 2. interface: PROFINET RT, 3. interface: Ethernet, 4. interface: PROFIBUS, 1 ns bit-performance, SIMATIC memory card (min. 2 GB) necessary |
| 6ES7518-4AX00-1AC0 | SIMATIC S7-1500, CPU 1518-4 PN/DP MFP, inclusive C/C++ Runtime and OPC UA Runtime license working memory 4 MB for program and 20 MB for data, 1. interface: PROFINET IRT with 2 port switch, 2. interface: PROFINET RT, 3. interface: Ethernet, 4. interface: PROFIBUS, 1 ns bit-performance, SIMATIC memory card (min. 2 GB) necessary |
| 6ES7511-1CK01-0AB0 | SIMATIC S7-1500 Compact CPU CPU 1511C-1PN, central processing unit with working memory 175 KB for program and 1 MB for data, 16 digital inputs, 16 digital outputs, 5 analog inputs, 2 analog outputs, 6 high speed counters, 4 high speed outputs for PTO/PWM/frequency output 1. interface: PROFINET IRT with 2 port switch, 60 NS bit-performance, incl. front connector push-in, SIMATIC memory card necessary |
| 6ES7512-1CK01-0AB0 | SIMATIC S7-1500 Compact CPU CPU 1512C-1 PN, central processing unit with working memory 250 KB for program and 1 MB for data, 32 digital inputs, 32 digital outputs, 5 analog inputs, 2 analog outputs, 6 high speed counters, 4 high speed outputs for PTO/PWM/frequency output 1. interface: PROFINET IRT with 2 port switch, 48 NS bit-performance, incl. front connector push-in, SIMATIC memory card necessary |
| 6ES7511-1FK02-0AB0 | SIMATIC S7-1500F, CPU 1511F-1 PN, CENTRAL PROCESSING UNIT WITH WITH WORKING MEMORY 225 KB FOR PROGRAM AND 1 MB FOR DATA, 1. INTERFACE: PROFINET IRT WITH 2 PORT SWITCH, 60 NS BIT-PERFORMANCE, SIMATIC MEMORY CARD NECESSARY |
| 6ES7513-1FL02-0AB0 | SIMATIC S7-1500F, CPU 1513F-1 PN, CENTRAL PROCESSING UNIT WITH WORKING MEMORY 450 KB FOR PROGRAM AND 1.5 MB FOR DATA, 1. INTERFACE: PROFINET IRT WITH 2 PORT SWITCH, 40 NS BIT-PERFORMANCE, SIMATIC MEMORY CARD NECESSARY |
| 6ES7515-2FM01-0AB0 | SIMATIC S7-1500F, CPU 1515F-2 PN, Central processing unit with work memory 750 KB for Program and 3 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface: PROFINET RT, 30 ns bit performance, SIMATIC Memory Card required |
| 6ES7516-3FN01-0AB0 | SIMATIC S7-1500F, CPU 1516F-3 PN/DP, Central processing unit with work memory 1.5 MB for program and 5 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface: PROFINET RT, 3rd interface: PROFIBUS, 10 ns bit performance, SIMATIC Memory Card required |
| 6ES7517-3FP00-0AB0 | SIMATIC S7-1500F, CPU 1517F-3 PN/DP, Central processing unit with Work memory 3 MB for Program and 8 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface: PROFINET RT, 3rd interface: PROFIBUS, 2 ns bit performance, SIMATIC Memory Card required |
| 6ES7518-4FP00-0AB0 | SIMATIC S7-1500F, CPU 1518F-4 PN/DP, Central processing unit with work memory 6 MB for program and 20 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface: PROFINET RT, 3rd interface: Ethernet, 4th interface: PROFIBUS, 1 ns bit-performance, SIMATIC Memory Card required |
| 6ES7518-4FX00-1AC0 | SIMATIC S7-1500F, CPU 1518F-4 PN/DP MFP, INCLUSIVE C/C++ RUNTIME AND OPC UA RUNTIME LICENSE WORKING MEMORY 6 MB FOR PROGRAM AND 20 MB FOR DATA, 1. INTERFACE: PROFINET IRT WITH 2 PORT SWITCH, 2. INTERFACE: PROFINET RT, 3. INTERFACE: ETHERNET, 4. INTERFACE: PROFIBUS, 1 NS BIT-PERFORMANCE, SIMATIC MEMORY CARD NECESSARY |
| 6ES7511-1TK01-0AB0 | SIMATIC S7-1500T, CPU 1511T-1 PN, Central processing unit with Work memory 225 KB for program and 1 MB for data, 1st interface: PROFINET IRT with 2-port switch, 60 ns bit performance, SIMATIC Memory Card required |
| 6ES7511-1UK01-0AB0 | SIMATIC S7-1500T, CPU 1511TF-1 PN, Central processing unit with Work memory 225 KB for program and 1 MB for data, 1st interface: PROFINET IRT with 2-port switch, 60 ns bit performance, SIMATIC Memory Card required |
| 6ES7515-2TM01-0AB0 | SIMATIC S7-1500T, CPU 1515T-2 PN, Central processing unit with work memory 750 KB for program and 3 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface, Ethernet, 30 ns bit performance, SIMATIC Memory Card required |
| 6ES7515-2UM01-0AB0 | SIMATIC S7-1500T, CPU 1515TF-2 PN, Central processing unit with work memory 750 KB for program and 3 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface, Ethernet, 30 ns bit performance, SIMATIC Memory Card required |
| 6ES7516-3TN00-0AB0 | SIMATIC S7-1500T, CPU 1516T-3 PN/DP, Central processing unit with 1.5 MB RAM for program and 5 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface, Ethernet, 3rd interface, PROFIBUS, 10 ns bit performance, SIMATIC Memory Card required |
| 6ES7516-3UN00-0AB0 | SIMATIC S7-1500TF, CPU 1516TF-3 PN/DP, Central processing unit with 1.5 MB RAM for program and 5 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface, Ethernet, 3rd interface, PROFIBUS, 10 ns bit performance, SIMATIC Memory Card required |
| 6ES7517-3TP00-0AB0 | SIMATIC S7-1500T, CPU 1517T-3 PN/DP, Central processing unit with work memory 3 MB for program and 8 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface, Ethernet, 3rd interface, PROFIBUS, 2 ns bit performance, SIMATIC Memory Card required |
| 6ES7517-3UP00-0AB0 | SIMATIC S7-1500TF, CPU 1517TF-3 PN/DP, Central processing unit with work memory 3 MB for program and 8 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface, Ethernet, 3rd interface, PROFIBUS, 2 ns bit performance, SIMATIC Memory Card required |
___________________________________
Để biết thêm thông tin, vui lòng liên hệ với chung tôi!
CÔNG TY TNHH CÔNG NGHỆ TC-TECH
Địa chỉ: 100/106 Đường số 3, P. 9, Q. Gò Vấp, TPHCM
Hotline/Zalo: 0906 7654 89
Email: Sales@tctech.com.vn
